| Electrical | |
| Model | GPS-C MU 1/… |
|---|---|
| Frequency | 370 – 470 MHz |
| Antenna Type | Mobile antenna |
| Max. Input Power | 25 W |
| Polarisation | Vertical |
| Impedance | 50 Ω |
| VSWR | < 1.3:1 @ f.res. |
| Bandwidth | ≥ 60 MHz @ VSWR ≤ 2.0 |
| Gain (EIA RS-329-1) | 0 dB |
| Mechanical | |
| Materials | Whip : Black-chromed, conical stainless steel Black-chromed brass Mount : Weather- and shockproof plastics Black-chromed brass |
|---|---|
| Colour | Black |
| Historic Brand | Amphenol Procom |
| Antenna Mount Type | Hole Mount |
| Height | Approx. 160 mm / 6.30 in. |
| Weight | Approx. 0.05 kg / 0.11 lb. |
| Mounting | On the GPS-Combi mount |
This product doesn’t have any diagrams yet.
| Model | Product No. | Model | Add To Quote |
|---|---|---|---|
|
GPS-C MU 1/… |
132000145 | GPS-C MU 1/… | |
|
GPS-C MU 1/370-430 MHz |
132000405 | GPS-C MU 1/370-430 MHz | |
|
GPS-C MU 1/406-470 MHz |
132000406 | GPS-C MU 1/406-470 MHz |
You need to be logged in into your account to view downloadable documents.
Do not use sealer on rubber gasket or other places.
The antenna should always be tuned using an VSWR-meter. The cutting diagram below serves as a guide for this procedure.
Hereby Amphenol Procom declare that the product type GPS-C MU 1/… is in compliance with EU Directive 2014/53/EU and
the UK Radio Equipment Regulations 2017 (S.I. 2017 No. 1206).
