MA160PS00
Electrical
Model MA160PS00
Frequency 380 – 470 MHz
Antenna Type Lambda/4
Max. Input Power 25 W
Impedance 50 Ω
Gain 0 dBd
VSWR < 2.0:1
Mechanical
Termination Low Loss RG58 (4.50 m) + FME(f) socket fitted
Colour Black (RAL 9005)
Historic Brand Amphenol Procom
Antenna Mount Type Hole Mount
Dimensions 100 x 50 x 5 mm / 3.93 x 1.96 x 0.19 in.
Weight Approx. 0.225 kg / 0.50 lb.
  • This Mobile antenna covering 380 – 470 MHz band.
  • Low profil design.
  • This Mobile antenna have a low profile design which enable to be installed in locations where it is not practical for a normal antenna to be located.
  • It can be mounting on either front or rear windscreens, or alternatively covertly installed within the vehicle, so that it is not visible.
  • The absence of external whip avoids any problems caused by vandalism, windscreenwipers, carwashes …..
